9dBi Antenna
€ 87.90 EUR
excl. VAT
This is the 9dBi Panel Antenna launched by Chainway. With the characteristics of fast reading/writing speed, while it could support long-distance reading and bulk-tags reading with the assurance of high data security. The device is portable, lightweight, and effortless to install, and intermittently has a high IP protection rating. Keeping this in consideration, Ant-RC09-255/255 is an ideal antenna to be deployed in various industries like logistics, warehousing, transportation, retail, medical treatment, electricity power, finance, ticket management, and livestock industry, etc.
Fast Read & Write
Long Read & Write distance
IP67
No items found.
Compatible accessories
9/12dBi Antenna Cable LMR200-1M
1 meter for UR4/UR8 with 9/12dBi Antenna.
Loss of signal 0,3DBi/m
€ 27.90 EUR
excl. VAT
9/12dBi Antenna Cable LMR200-5M
5 meter for UR4/UR8 with 9/12dBi Antenna.
Loss of signal 0,3DBi/m
€ 38.90 EUR
excl. VAT
9/12dBi Antenna Cable LMR200-15M
15 meter for UR4/UR8 with 9/12dBi Antenna.
Loss of signal 0,3DBi/m
€ 54.90 EUR
excl. VAT
9/12dBi Antenna Cable LMR240-5M
5 meter for URA4 with 9/12dBi Antenna.
Loss of signal 0,25DBi/m
€ 33.90 EUR
excl. VAT
9/12dBi Antenna Cable LMR240-15M
15 meter for URA4 with 9/12dBi Antenna.
Loss of signal 0,25DBi/m
€ 62.90 EUR
excl. VAT
9/12dBi Antenna Cable LMR400-5M
5 meter for UR4/UR8 with 9/12dBi Antenna.
Loss of signal 0,12DBi/m
€ 46.90 EUR
excl. VAT
9/12dBi Antenna Cable LMR400-10M
10 meter for UR4/UR8 with 9/12dBi Antenna.
Loss of signal 0,12DBi/m
€ 73.90 EUR
excl. VAT
9/12dBi Antenna Cable LMR400-15M
15 meter for UR4/UR8 with 9/12dBi Antenna.
Loss of signal 0,12DBi/m
€ 96.90 EUR
excl. VAT
9/12dBi Antenna Cable U300 5M
5 meter cable for U300 with 9/12dBi Antenna.
€ 27.90 EUR
excl. VAT
9/12dBi Antenna Cable U300 15M
15 meter cable for U300 with 9/12dBi Antenna.
€ 65.90 EUR
excl. VAT
Standard accessories
No compatible accessories for this product.
Integration with your molding line
9dBi Antenna
comes with a full set of specs, options, and accessories—review the details below to see how it fits your setup.
Specifications & docs
Connector Type N-Type Female
Dimensions H*W*D (mm) 255*255*30(mm)
Weight 1.27kg (with mounting bracket)
Radome Material ABS
Radome color white
Radiant board material aluminum
Operating Temperature -40ºC/+60ºC
Sealing IP67
Installation mode Pole mounted or Wall mounted
Support Pole Diameter φ30-φ50(mm)
Rated Wind Velocity 60m/s
Frequency Range 865-868MHz
Polarization Type RHCP
Gain 9dBi
3dB Beam-Width. H-Plan 60°
3dB Beam-Width. E-Plan 55°
VSWR ≤1.3
Front to back Ratio ≥17dB
Input Impedance 50Ω
Max Input Power 20W
Lightning Protection DC Grounded
