CM710-1 UHF RFID Module (1-Port)

€ 175.90 EUR

excl. VAT

CM710-1 is a 1-Port RFID module based on Impinj E710 chip. With the support of Impinj Gen2X, this module provides superior UHF performance. It can be integrated in mobile RFID readers, fixed RFID readers, card issuers and etc. With high integration level, it is small in size, low in power consumption, resistant to electromagnetic interference and good at heat dispersion. The module appeals to challenging industries like warehousing, logistics, apparel, production lines and such.

Excellent heat dissipation

Excellent heat dissipation

Superior stability

Superior stability

Compact Size

Compact Size

Low Power Design

Low Power Design

Impinj Gen2X

Impinj Gen2X

Compatible accessories

No compatible accessories for this product.

Standard accessories

No compatible accessories for this product.

Integration with your molding line

CM710-1 UHF RFID Module (1-Port)

comes with a full set of specs, options, and accessories—review the details below to see how it fits your setup.

Specifications & docs

Dimensions 57.2 mm x 36.8 mm x 7.6 mm

‍Weight 26.0 g

Reading Rate 950+ tags/s

‍Reading Range Up to 30m (with 4dBi antenna & M750 tag)

Connector 12 PIN FPC Connector

‍Host Communication UART 3.3V TTL LevelBaud Rate: 115200bps

RF Chip Impinj E710

‍Impinj Gen2X Supported

‍Air Interface Protocol EPCglobal Gen2 ( ISO18000-6C )

‍Working Frequency 865-868 MHz

‍Output Power 1-30dBm adjustable; 1dB step interval; +/- 0.5dB precision

‍Output Power Flatness +/- 0.2dB

‍Antenna Interface 50Ω RF connector MMCX Receptacle

‍Regions Supported ETSI 865.6-867.6 MHz

‍Receive Sensitivity < -87 dBm

‍Tag RSSI Supported

‍Antenna Detector Supported

‍Ambient Temp Monitor Supported

‍Working Mode Single/DRM

Input Voltage DC 3.5-5.25V

‍Power Consumption in RF Output Mode 7.5W

‍Power Consumption in Standby Mode（EN high TTL level）0.175W

‍Power Consumption in Power Down Mode（EN low TTL level）42.5uW

CM710-1 Data Sheet
